6 ATM

  • In-Line Special Filter with Mini Valve

    3385

    Code Inlet/Outlet Mesh Discharge

    (m³/h)

    Packing

    (pcs/cart)

    SCREEN
    3385/0083 1″ 80Black 8 30 H
    3385/0123 1″ 120Red 8 30 H
    3385/0153 1″ 150Brown 8 30 H
    3385/0183 1″ 180Yellow 8 30 H
    3385/0084 1 ¼″ 80Black 8 30 H
    3385/0124 1 ¼″ 120Red 8 30 H
    3385/0154 1 ¼″ 150Brown 8 30 H
    3385/0184 1 ¼″ 180Yellow 8 30 H
    Note: Special ilters can be ordered with NPT thread.
    When ordering please alter the fifth digit of the code to 1. Example: Special Filter 1″ with mini valve NPT 80mesh code: 3385/1083
    Load More
  • In-Line Special Filter

    3384 - 3386

    Code Inlet/Outlet Mesh Discharge

    (m³/h)

    Packing

    (pcs/cart)

    SCREEN
    3384/0083 1″ 80Black 8 40 H
    3384/0123 1″ 120Red 8 40 H
    3384/0153 1″ 150Brown 8 40 H
    3384/0183 1″ 180Yellow 8 40 H
    3384/0084 1 ¼″ 80Black 8 35 H
    3384/0124 1 ¼″ 120Red 8 35 H
    3384/0154 1 ¼″ 150Brown 8 35 H
    3384/0184 1 ¼″ 180Yellow 8 35 H
    DISK
    3386/0123 1″ 120Red 6 40 H
    3386/0154 1 ¼″ 120Red 6 35 H
    Note: Special ilters can be ordered with NPT thread.
    When ordering please alter the fifth digit of the code to 1. Example: SpecialFilter 1″ NPT 80mesh code: 3384/1083
    Load More
  • In-Line Large Filter

    3382 - 3383

    Code Inlet/Outlet Mesh Discharge

    (m³/h)

    Packing

    (pcs/cart)

    SCREEN
    3382/0042 ¾″ 40Blue 5 60 H
    3382/0062 ¾″ 60Grey 5 60 H
    3382/0082 ¾″ 80Black 5 60 H
    3382/0122 ¾″ 120Red 5 60 H
    3382/0043 1″ 40Blue 6 60 H
    3382/0063 1″ 60Grey 6 60 H
    3382/0083 1″ 80Black 6 60 H
    3382/0123 1″ 120Red 6 60 H
    3382/0153 1″ 150Brown 6 60 H
    DISK
    3383/0122 ¾″ 120Red 4 60 H
    3383/0123 1″ 120Red 5 60 H
    3383/0153 1″ 155Black 5 60 H
    Note: 1″ filters can be ordered with NPT thread.
    When ordering please alter the fifth digit of the code to 1. Example: Filter Large 1″ NPT 60mesh code: 3382/1063
    Load More
  • In-Line Small Filter

    3372 - 3373

    Code Inlet/Outlet Mesh Discharge

    (m³/h)

    Packing

    (pcs/cart)

    SCREEN
    3372/0062 ¾″ 60Grey 5 80 H
    3372/0082 ¾″ 80Black 5 80 H
    3372/0122 1″ 120Red 5 80 H
    3372/0043 1″ 40Blue 6 80 H
    3372/0063 1″ 60Grey 6 80 H
    3372/0083 1″ 80Black 6 80 H
    3372/0123 1″ 120Red 6 80 H
    DISK
    3373/0122 ¾″ 120Red 4 80 H
    3373/0123 1″ 120Red 5 80 H
    Note: 1″ filters can be ordered with NPT thread.
    When ordering please alter the fifth digit of the code to 1. Example: In-Line Small Filter 1″ NPT 60mesh code: 3372/1063
    Load More
  • Elbow Large Filter (screen)

    3391

    Code Inlet/Outlet Mesh Discharge

    (m³/h)

    Packing

    (pcs/cart)

    3391/0625 1″ x 25 60Grey 7 50 E
    3391/0825 1″ x 25 80Black 7 50 E
    3391/1225 1″ x 25 120Red 7 50 E
    3391/0632 1″ x 32 60Grey 7 50 H
    3391/0832 1″ x 32 80Black 7 50 H
    3391/1232 1″ x 32 120Red 7 50 H
    Load More
  • Elbow Small Filter (screen)

    3390

    Code Inlet/Outlet Mesh Discharge

    (m³/h)

    Packing

    (pcs/cart)

    3390/0420 1″ x 20 40Blue 7 50 E
    3390/0620 1″ x 20 60Grey 7 50 E
    3390/0820 1″ x 20 80Black 7 50 E
    3390/1220 1″ x 20 120Red 7 50 E
    3390/0425 1″ x 25 40Blue 7 50 E
    3390/0625 1″ x 25 60Grey 7 50 E
    3390/0825 1″ x 25 80Black 7 50 E
    3390/1225 1″ x 25 120Red 7 50 E
    3390/0432 1″ x 32 40Blue 7 50 E
    3390/0632 1″ x 32 60Grey 7 50 E
    3390/0832 1″ x 32 80Black 7 50 E
    3390/1232 1″ x 32 120Red 7 50 E
    For direct connection with dripline Φ20 use Dripline Nut (code 3241/3202) and Grip Ring (code 3231/0020).
    Load More
  • Tee Large Filter (screen)

    3486

    Code Inlet/Outlet Mesh Discharge

    (m³/h)

    Packing

    (pcs/cart)

    3486/2063 20 x 1″ x 20 60Grey 7 50 H
    3486/2083 20 x 1″ x 20 80Black 7 50 H
    3486/2123 20 x 1″ x 20 120Red 7 50 H
    3486/2153 20 x 1″ x 20 150Brown 7 50 H
    3486/3043 25 x 1″ x 25 40Blue 7 50 H
    3486/3063 25 x 1″ x 25 60Grey 7 50 H
    3486/3083 25 x 1″ x 25 80Black 7 50 H
    3486/3123 25 x 1″ x 25 120Red 7 50 H
    3486/4043 32 x 1″ x 32 40Blue 7 40 H
    3486/4063 32 x 1″ x 32 60Grey 7 40 H
    3486/4083 32 x 1″ x 32 80Black 7 40 H
    3486/4123 32 x 1″ x 32 120Red 7 40 H
    For direct connection with dripline Φ20 use Dripline Nut (code 3241/3202) and Grip Ring (code 3231/0020).
    Load More
  • Tee Small Filter (screen)

    3476

    Code Inlet/Outlet Mesh Discharge

    (m³/h)

    Packing

    (pcs/cart)

    3476/1063 16 x 1″ x 16 60Grey 7 50 E
    3476/1083 16 x 1″ x 16 80Black 7 50 E
    3476/1123 16 x 1″ x 16 120Red 7 50 E
    3476/2043 20 x 1″ x 20 40Blue 7 50 E
    3476/2063 20 x 1″ x 20 60Grey 7 50 E
    3476/2083 20 x 1″ x 20 80Black 7 50 E
    3476/2123 20 x 1″ x 20 120Red 7 50 E
    3476/3043 25 x 1″ x 25 40Blue 7 50 E
    3476/3063 25 x 1″ x 25 60Grey 7 50 E
    3476/3083 25 x 1″ x 25 80Black 7 50 E
    3476/3123 25 x 1″ x 25 120Red 7 50 E
    3476/4043 32 x 1″ x 32 40Blue 7 50 E
    3476/4063 32 x 1″ x 32 60Grey 7 50 H
    3476/4083 32 x 1″ x 32 80Black 7 50 H
    3476/4123 32 x 1″ x 32 120Red 7 50 H
    For direct connection with dripline Φ20 use Dripline Nut (code 3241/3202) and Grip Ring (code 3231/0020).
